conf2On the 12th May 2015 in Montreal Canada the first Rock Bowl Team from South Africa took part in the first International Society for Rock Mechanics (ISRM) Rock Bowl Challenge. The team consisted of 4 members who were chosen according to the following requirements:

  • The Rock Bowl team must consist of 4 members who’s ages must be 35 and younger.
  • Four young graduates working in the rock engineering field (with BSc or MSc and one PHD)
  • There is no cost to participate in the Rock Bowl.
  • The participating teams are responsible for all costs associated with registration and travel to the ISRM Congress 2015. There is no subsidy or sponsorship for the participating teams.

On the 12th May 2015 at 15:00 the competition began. In true South African style a quick “regmaaker” was gulped down and they were ready to compete against Brazil, China, South Korea and Canada.

The competition was structured in a similar “flink dink” way whereby a Rock Engineering related question is asked by a presenter and each team sitting opposite to each other needs to tap a buzzer which secures the question. They then have 10 seconds to answer the question. If it is answered correctly the team is awarded 10 points as well as a bonus question. If the bonus question is answered correctly, 20 points are awarded to the team. All the teams competed against each other in a pool setup, whereby the final was decided.
The first round was South Africa Vs. Canada. Unfortunately South Africa lost the first round, whereby we had one more round left in the pool which was against Brazil. South Africa narrowly lost this round as well and therefore forfeited the final position to Brazil. Brazil entered two teams which both made it to the final. The winners for the Rock Bowl 2015 was Brazil.
Even though the South African team did not win, it was an experience of a life time. We would all like to thank SANIRE and the associated sponsors for making this possible and to TEAM SOUTH AFRICA for a great experience on an international stage.

For more information on ISRM and the Rock Bowl 2015 please visit the ISRM website.

Some pictures from the event


Special thanks to the Sponsors


temogoFull Name: Temogo Itholeng

Position: Rock Engineer (Unisel and Joel, Welkom, Free-State)

Company/ Organisations: BLA Harmony

Date and Place of Birth: 1983 May 01

Education: BSc Hons Mining-Wits University

First Job: Leaner Miner Rustenburg Townlands shaft

Personal Best Achievement/s: Getting to sign that legal appointment you realise "this is it".

Philosophy of Life: "Surely it can't be that difficult"

Favourite Food/Drink: Some braaivleis and beer

Favourite Sport: Not really into sport, but enjoy some superbike racing

How did your career in the mining industry begin and where are you now?
It began when I got a scholarship with Wits to do mining engineering in 2002, and 13 years later I am the appointed Rock Engineer at Joel and Unisel shafts.

Why did you choose Rock Engineering?
Actually unplanned and purley coincidental, Anglo-platinum was in a drive to recruit for their Rock Engineering Dept, ran by Dougall Fraser, they gave presentations at Wits as part of the drive and I attended one of those presentations and was interested since then.

Please tell us a bit more about your career journey?
Started off as a leaner miner at Townlands shaft as part of a requirement for the Mining Eng Degree, and realised soon enough I was not cut out for to be a "miner", following completion of my degree (under Rock engineering dept, ADC), started as a trainee in 2006 pursuing my SCO cert. Became SCO at Boschfontein and then moved to Free-State to work for BLA in 2008. Two years later I acquired COMREC in 2010, appointed Rock Eng at Target 3 shaft 2012 until its closure in 2014.

In your opinion, what are some of the challenges that the fraternity is currently facing?
Being in the operations and all the associated responsibilities we tend to lose touch with the technical side associated with the Engineering. We have become guards against DMR in our attempts to keep complying. Unlike Geotechnical consultants whom are only involved for a part of the project(design phase).

What are some areas that you believe will become of increasing importance in the near future of the rock engineering discipline?
As mines become depleted, commodity prices falling, mines getting deeper, difficult and more dangerous and DMR getting stricter we need to look at what can the Rock Engineers do to assist in the survival of the industry.

What advice would you offer people aspiring to be in your position?
All I can say is "surely it can't be that difficult", butt on the chair type approach has worked for most people (committed studying).

Who is your role model/ mentor?
I think Deon Louw, particularly his laid back demeanour in times of heightened stress.

What is the best advice you have ever been given?
If you are confident that you did what can possibly be expected of you, by your peers and critics then you don't have to worry.

heinFull Name: Heinrich Greeff

Position: Rock Engineer

Company/ Organisations: New Concept Mining

Date and Place of Birth: 23 September 1984, Parys (Freestate)

Education: Tertiary level Physics and Mathematics, Rock Engineering Certificate

First Job: Assistant Strata Control Officer at AngloGold Ashanti Moab Khotsong Mine

Personal Best Achievement/s: Still have to achieve something of note

Philosophy of Life: Good judgement comes from experience, experience comes from bad judgement – Jim Horning

Favourite Food/Drink: I think it's a tie between biltong and wine gums

Favourite Sport: Anything that takes you into nature

How did your career in the mining industry begin and where are you now?
I started working as an Assistant Strata Control Officer at AngloGold Ashanti on Moab Khotsong mine in 2009. Worked in the deep level gold mines till 2013 and then relocated to the diamond fields under De Beers Consolidated Mines. Currently working as a Rock Engineer for New Concept Mining.

Why did you choose Rock Engineering?
Lourens Scheepers came to recruit Physics students at the Northwest University in my final year of studying. His passion for the discipline was contagious and there was opportunity to further develop the science through research. I joined because I wanted to make a difference and be part of that development.

Please tell us a bit more about your career journey?
Most of my time in Rock Engineering was spent on deep level gold mines. I've learned to understand stress and rock movement there a lot better than I imagined to be possible anywhere else. I enjoyed linking theory and actuals and that made it apparent to me that there is room for improvement in our current understanding. Moving away from the gold mines to the diamond fields unearthed my understandings because all of the sudden stress was insignificant and gravity called the shots. Looking back over the few years I've been part of our fraternity, I am excited over what the future might hold.

In your opinion, what are some of the challenges that the fraternity is currently facing?
Our mines are some of the best laboratories (worldwide) for research and exploring our understanding of mining, however, the Rock Engineering guys on the mines are often consumed by the amount of paperwork that they are responsible for. This halts them from having the time and energy to explore and be creative in their understanding. It is a challenge to not let work obstruct you from doing your work...

What are some areas that you believe will become of increasing importance in the near future of the rock engineering discipline?
I believe that in future we will come to understand stress and rock movement better and that this will drastically change the way we perceive quasi static and dynamic events. I believe that Rheology will come into play and that there will be a distinction made between what portions of each occurrence was related to stress stimulus and what was just a result of rock mass movement.

What advice would you offer people aspiring to be in your position?
Don't take shortcuts, just study the entire syllabus – it's worth it.

Make time to look at and monitor the small things in your mining environment. Make time for those interesting trips just to remind you of how cool mining actually is.

Who is your role model/ mentor?
Johan Hanekom is my role model and I strive to have his understanding of physics, mathematics and how to apply this every day.

I have had many mentors through my career this far, but none as influential as Gary Williams. He forever changed the way I look at mining and the role we play in it.

What is the best advice you have ever been given?
You have two ears, two hands and one mouth; use them in that ratio

From the very beginning of mining operations on the Witwatersrand, the absence of large quantities of suitable and readily available timber in the vicinity decreed that stopes were supported by mine poles or sticks at the immediate face where necessary, and these served well into the back area. Scatter piles or shrinkage piles of broken ore, held in place by timber or metal poles hitched into the hanging and footwall, to serve as working platforms, also provided a support function in steep stopes. Hangingwall control of the back area, particularly during shrinkage recovery operations, was achieved by waste packing. Waste-filled cribs, or pigstyes, and concrete disc packs were later introduced when the reef dip started to flatten out. Sometimes intense support of the face working area with relatively little in the way of back-area support was mooted. Sand-filling was also occasionally employed as workings became deeper and flatter, but, as this was of the post-fill variety, it was of little consequence as a hangingwall support measure. More importantly, pillars of unmined ore acted as the de-facto means of local and regional hangingwall support, but the size, position and distribution of these pillars, particularly in the earlier years, was generally dictated more by grade distribution considerations than by support or rock mechanics considerations.

Nevertheless, whether by accident or design, these methods were ideally suited to the extraction of the extensive, narrow, tabular, brittle, hard-rock orebodies of the Witwatersrand at these relatively shallow depths (<1000mbs). Timber mat packs on their own, for example, would have been entirely inappropriate, and could have led to sudden, extensive backbreaks, with all of the attendant ramifications of this type of stope failure.

However, there was an intrinsic drawback associated with the pillar support method, and this manifested itself very soon after the beginning of the new century. With the rapid increase in depth of the Central Rand workings mentioned above, support pillars and other pillars, such as inter-stope remnants, started to fail violently as a result of increasing rock pressure. Catastrophic pressure bursts (rockbursts) were experienced underground and severe earth tremors were felt on surface. While the effects and consequences of these incidents were clear, the underlying causes, and therefore the appropriate preventative measures to be applied, were not all that well understood at first. It was, nevertheless, eventually recognised that the phenomenon was somehow connected with depth, pressure, stoping spans, pillars and convergence, or subsidence as it was then called, and even the exacerbating role of geological anomalies such as faults and dykes was recognised. But appreciation of the key to the mystery, that of stored elastic strain energy in the rockmass giving rise to destructive compressive waves and shear waves when released by sudden failure in the rockmass, was entirely lacking in those early years.

Three separate government commissions were set up in the course of the first three decades of the new century to enquire into the causes and remedial measures to be applied by the industry. Amongst other things, the commissions suggested that the formation of under-designed on-reef pillars, and particularly of remnants, be avoided in workings, but, as mentioned, the lack of fundamental understanding prevented them from making more profound, far-reaching and definitive pronouncements and recommendations on the issue.

The Association of Mine Managers, formed in 1892 to promote the general advancement of mining in the country, and always concerned with safety, particularly underground safety, now took a dominant lead in trying to understand and prevent or ameliorate these events. The Transvaal Chamber of Mines initiated the practice of printing and distributing technical papers and discussions that were presented at regular meetings of the Association, starting in 1931. A volume entitled 'Some Aspects of Deep Level Mining on the Witwatersrand Gold Mines with Special Reference to Rock Bursts' covered the papers read before the Association on the subject in the years 1932 and 1933. At that time, more than 700 earth tremors, or mine tremors, per year were being recorded in the Johannesburg area alone (two per day!).

The healthy and robust debate between mine managers who were holders of various, sometimes conflicting, theories on the subject makes interesting reading, but with the benefit of hindsight it is sometimes frustrating to see how close some of the greatest names in the industry came without actually cracking the nut. But then the war years of the 1940s, however dark they may have been for the world, heralded the long-awaited breakthrough, and can be regarded as the watershed years during which mine-scale experiments in support methodologies and mining layout strategies started to yield the technical understanding and basic principles of deep-level mining that we take for granted today.

The first breakthrough came in the form of a paper presented by H.V. Curtis on behalf of the late H.W. Ardler (who featured prominently in previous work on the subject), supported by no less a personage than C.W. Biccard Jeppe, in which it was suggested for the first time that elasticity in rocks and rockmasses may probably play a fundamental causative role in the phenomenon of underground pressure bursts. It was also suggested for the first time that a permanent body should be established to deal with the question of rockbursts.

There were many insightful mining men of that era, but one name stands out above all of the rest. Following well documented experimentation at ERPM, F.G. ('Pinkie') Hill presented and published a number of ground-breaking papers during the course of the decade on subjects as diverse as destressing inclined shafts by over-stoping (prompted by his description of the complete closure of 100m of the Driefontein Tertiary Incline Shaft by a rockburst); using sticks as the dominant means of hangingwall control in stopes (prompted by previous work on the theory of using 'incompressible' support to prevent bending and sag of hangingwall strata); and, of course, his pioneering introduction of the longwall stoping system in the Hercules Section at ERPM in 1940. Typically he did not take credit for this innovation which he said had been practiced for generations, but he did assert his belief that on the mines of the Central Rand where payability was over 65% some form of longwall stoping would be necessary at depths below 8500 feet (2500m) below surface.

Pinkie Hill must, without doubt, be regarded as one of the foremost thinkers, doers and leaders in the field of rock engineering. He remained actively involved well into the 1960s. Not only did he introduce and champion the now familiar and indispensable concepts of longwalling and over-stoping in deep mining environments, he was also the first to harness the expertise within the engineering research institutions of the Council for Scientific and Industrial Research, from which flowed his work on pre-conditioning blasting. He was instrumental in persuading authorities of the need to establish research facilities within the Chamber of Mines dedicated to solving deep-level and other mining problems (from which the CoM Research Organisation evolved). And it was he who initiated the introduction, recruitment and training of dedicated rock engineering practitioners assigned the task of establishing and expanding the discipline within each of the large mining groups. The cliché of being able to see far into the future only because one is standing on the shoulders of the giants of the past is usually associated with the world of physics, but it can perhaps be applied with equally veracity to the mining engineers and managers of this time.

dave  This story was written by Dave Arnold.
Please feel free to contact Dave with any historical stories for the next edition.



The SANCOT conference for mechanised underground excavation in mining and civil engineering was recently held in Durban in April 2015. The conference was compact; however delegates and stakeholders from as far afield as Germany, Switzerland, Turkey and Lesotho were represented, drawing from the consulting through to manufacturing and government arenas. The conference was presented over two days followed by a site visit to the Durban Harbour tunnel (pictures, inset) which was constructed with the use of a tunnel boring machine. Jeanne Walls and William Joughin represented SANIRE and SRK at the conference.

In the mining sector, tunnelling is integral to establishment of accesses and ore handling facilities. Whereas conventional drill and blast methods have historically dominated tunnel development and support installation, particularly in South African mines, the move to mechanisation in shaft sinking, horizontal and vertical raiseboring and support installation is rapidly entering the area of conventional practices. Presentation topics included mechanised installation of support (Geobrugg, SMEC), tunnel boring technology from an EPCM (WorleyParsons) and manufacturing (Master Drilling and Petra Diamonds) perspective and geotechnical considerations for large-scale projects (SRK).

In the civil sector, managing the risk of boring tunnels for infrastructure in developed urban areas, beneath airports (Herrenknecht), suburbs (GIBB, Gautrain) and the Durban harbour (eThekwini Municpality) made for some enlightening discussions. Microtunnels (Hatch), sea outfalls (Herrenknecht) and asset management (GIBB) completed the technical topics.

Going forward, SANCOT is in the process of revitalising its portfolio under the chair of Ron Tluczek (AECOM) who attended the annual ITA conference in May in Dubrovnik, Croatia. Included in the portfolio is several working groups commissioned under the ITA to develop guidelines for tunnelling in various areas of interest, including vertical tunnelling and asset management, amongst others. The Young Professionals' Forum (YPF) is a new initiative that falls under the ITA and intends to engage with SAICE, SANIRE and SAIMM to develop new talent while bridging the gap with seasoned experience. SANCOT expects to become increasingly involved in projects including the Lesotho Highlands Phase II and uMkhomazi Water Project in KwaZulu-Natal.

Finally, in case anyone thought the conference was all business, well, it was considered by some to be my greatest achievement to remain pink-faced and cheery with a hangover while negotiating a boat cruise out to open water on the last morning.

For more information, contact jwalls@srk.co.za or visit the webpage at http://www.saimm.co.za/sancot
SANCOT was formed in 1973 and is a founding member of the International Tunnelling Association

Article by Jeanne Walls, SRK Consulting

lucilleFull Name: Lucille Cilliers

Position: Rock Engineer

Company/ Organisations: Open House Management Solutions

Date and Place of Birth: 7 September 1968, Welkom Free State

Education: COMRE, AREC

First Job: Clerk at Senwes Cooperation, Klerksdorp

Personal Best Achievement/s: Obtaining my Rock Engineering qualifications in 7 years (of which 2010 was a gap year after I have obtained the COMRE certificate, and 2012 I looked after my father who suffered brain cancer and passed away in the same year. Strictly speaking 5 years of studying)

Philosophy of Life: Respect other people's way of thinking. 6+3=9, but so does 5+4 also produce the same answer. Your way of doing things is not necessarily the best or only way it can be done.

Favourite Food/Drink: Anything that my mother dishes up! Especially if it is oxtail!

How did your career in the mining industry begin and where are you now?
My career in the mining industry started on 21 August 1990 when I was appointed as clerk at the Trade Accounts Department of Hartebeestfontein Gold Mine. I worked in various sections of the mine's Accounts Department, but was then retrenched during 1999 when the mine downscaled just before DRD closed down. At the very same time of my retrenchment, a new door opened at the Rock Engineering Department where I started working as Secretary in October 1999. In February 2000 Open House Management Solutions was established and the mine's Rock Engineering department was outsourced to the newly founded company. I just transferred as secretary to the new company and then acted as Personal Assistant to Koos Bosman, the then Managing Director of Open House.

Working in the same position for almost eight years eventually became non-challenging and started to frustrate me. After complaining to Koos about my frustration, he encouraged me to start studying and directed me in the direction of becoming a Rock Engineer. On 7 August 2007 I undertook my first "experimental" underground visit and this was the beginning of a new life to me.

Why did you choose Rock Engineering?
Rock Engineering chose me! I do believe that this was directed by God who opened new doors and who also gave me the strength to start and to prevail in this career.

Please tell us a bit more about your career journey?
My Rock Engineering career started when someone else believed in my abilities - that I could do it, even before I thought so myself. I remember 6 August 2007 very well. I once again was complaining about my frustration and Koos suggested that I should consider a career in Rock Engineering. An hour later an underground visit for the next day was organised. After returning from the underground trip the next day, with a: "en was dit nou so erg?", Koos, handed Jager and Ryder's handbook to me. This posed an exciting challenge that I grabbed with both hands.

Since then I studied on and worked in different mining environments such as deep level gold mines, multi reef chrome mines, and open pit mines. I obtained the Chamber of Mines Rock Engineering Certificate in 2009 and the Advanced Rock Engineering Certificate during 2014. I'm currently part of the consulting team at Open House.

In your opinion, what are some of the challenges that the fraternity is currently facing?
In my opinion South Africa faces some of the most severe rock engineering challenges in the world with ageing mines and new developing mines creating a diverse scope of rock engineering demands. This ever-changing landscape requires people who are pro-active in their approach, and therefore Rock Engineers should be encouraged to equip themselves with unceasing knowledge in order not to stagnate - especially those on shafts who have become accustomed with what they have been doing for so long.

What are some areas that you believe will become of increasing importance in the near future of the rock engineering discipline?
I do believe that technology and new or better modelling programmes will become increasingly advanced and that the future of any professional rock engineer will depend on how technologically advanced his approach to design development will be.

What advice would you offer people aspiring to be in your position?
Making a career change took hard work, dedication, determination and a positive attitude and I must admit that I wouldn't have achieved this if it was not for those who stood by me. Ensure that you have relatives, friends and colleagues that support you! People made a difference - people who believed in me, people who gave me the chance and supported me. This also makes me believe that I can make a difference in other people's lives.

Who is your role model/ mentor?
Koos Bosman CEO of Open House Management Solutions. If it was not for his understanding, positive support and motivation, not to mention the Saturdays and public holidays he sacrificed helping me with the studies, I would most probably still be complaining about the disheartening office work.

What is the best advice you have ever been given?
From my father – budget and don't buy on credit

rock starFull Name: Thokozani Sidwell Habile

Position: Senior Rock Engineering Officer

Company/ Organisations: AngloGold Ashanti

Date and Place of Birth: 1986 04 30, Piet Retief, Mpumalanga

Education: BSc Honours Computational and Applied Mathematics (Wits)

First Job: Promoting Saturday Star at Clearwater mall (Roodeport)

Personal Best Achievement/s: Achieving my honors degree at Wits and Rock engineering ticket.

Philosophy of Life: Limitations are those you set in your mind, or permit others to set up for you.

Favourite Food/Drink: Pap and braai meat with gravy and spinach

Favourite Sport: Soccer, Cricket

How did your career in the mining industry begin and where are you now?

My career began at Wits University (2004-2008) where I completed my applied maths degree. In 2009 I started in the rock engineering department as an assistant strata control officer where I was doing the numerical modelling for west wits mines and doing instrumentations for projects in place. Then I felt a need of underground exposure which then directed me to Nostrada Rock Mechanics in the Rustenburg where I was working as a Strata control Officer for a year. A year later I moved to BLA (Harmony Kusasalethu mine) which was my first time working as a Rock mechanics officer in a Gold mine, I learned a lot there I must say. Due to personal and reason and moving closer to my family in Mpumalanga, year later I joined Great Basin Gold and by that time I just passed all my 3 Rock mechanics papers. I got retrenched after a month of working there then I returned to AngloGold Ashanti in October 2012 where I got my Rock engineering ticket after 5 attempts. I was appointed as Senior Rock Engineering Officer in 2015.

Why did you choose Rock Engineering?

Rock engineering is technical and it involves lot of mathematics for most decision made in the industry, so that makes it easy for me to understand the concepts used.

Please tell us a bit more about your career journey?

My career journey from high to university was nice and smooth, it started challenging when failed my practical 4 times and that frustrated me a lot because it never happen in my life. But that never stopped me from becoming a rock engineer in fact I became a better rock engineer because I started reading articles and researching about mining. Failing has helped me not only understand my mine but understand the principle of rock engineering so I can be able to apply my knowledge at any mine.

In your opinion, what are some of the challenges that the fraternity is currently facing?

There are 3 challenges I think rock engineering is facing.

  • Rock engineers in the shafts don't have enough time to research and design as shaft work require them to do underground visit and routine rock engineering work. We rely too much on work done by previous rock engineers.
  • There is a lack of transfer of knowledge from experienced rock engineers to the new up and coming ones.
  • The Strata Control Officers having to write reports for the Rock Engineering Practical with content, which they are not exposed to on daily basis.

What are some areas that you believe will become of increasing importance in the near future of the rock engineering discipline?

  • Understanding seismicity and Modelling will be more important as the mines are becoming deeper.
  • The legal responsibilities will be stricter as government is heading for zero harm in the mine industry.

What advice would you offer people aspiring to be in your position?

Do not take a decision that you won't be able to defend when problems arises in future.

Who is your role model/ mentor?

Mr Gary Dukes

What is the best advice you have ever been given?

"When in doubt say no".

Jaco le Roux
Brentley, Lucas and Associates Mining Consultants

A design criterion called the Dilution Stress-Strain Index (DSSI) was developed by Le Roux (2015) allowing the user to determine the possible failure into the hangingwall and sidewalls of an open stope. Using the following design criterion:


where q is the slope of the linear trend line,

σm = mean stress and can be mathematically expressed as follows:


where σ1σ2 and σ3 represents the major, intermediate, and minor principal stress, respectively (Ryder and Jager, 2002).

εvol = volumetric strain and can be mathematically expressed as follows:


where ε1, ε2 and ε3  and represents the major, intermediate, and minor principal strain, respectively (Ryder and Jager, 2002).

By applying the Dilution Stress-Strain Index (DSSI) where σm = 85MPa, which is the maximum allowable mean stress for open stope hangingwall failure as determined from the back analyses on Target Mine. Using Map3D, areas within the open stope hangingwall or sidewall can be identified were instability may occur. Figure 1 below indicates such areas in light grey around the open stope whereby the criterion was applied. The predicted failure corresponded very well with the actual observed failure in the hangingwall as shown by the Cavity Monitoring system (CMS) of the open stope plotted in red on Figure 1.

Figure 1 - Application of the Dilution Stress-Strain Index for hangingwall on a planned open stope and showing the final CMS of the open stope

When compared to the applied Mohr-Coulomb failure criterion developed for failure around open stopes using


The Mohr-Coulomb failure criterion results indicated that there will be major failure in the hangingwall and sidewalls of this stope as shown in light grey in Figure 2. When compared to the applied Hoek-Brown failure criterion developed for failure around open stopes using


The Hoek-Brown failure criterion results indicated that there will also be major failure in the hangingwall and sidewalls of this open stope as shown in light grey in Figure 3. These results do not correspond with the actual CMS of the open stope plotted in red on Figure 1. The results indicate that the effect of the intermediate stress and volumetric strain should not be underestimated.

Figure 2 - Application of the Mohr-Coulomb failure criterion on a planned open stope

Figure 3 - Application of the Hoek-Brown failure criterion on a planned open stope


Henning, J.G. and Mitri, H.S. (2007) Numerical modelling of ore dilution in
           blasthole stoping
(Vol 44. 5. pp. 692-703). International Journal of Rock
           Mechanics & Mining Sciences.

Le Roux, P.J. (2015). Measurement and Prediction of Dilution in a Gold Mine
           Operating with Open Stoping Mining Methods
(Unpublished Doctoral thesis).
           University of the Witwatersrand, South Africa.

Ryder, J.A. and Jager, A.J. (2002) A Textbook on Rock Mechanics for Tabular
           Hard Rock Mines
, The Safety in Mines Research Advisory Committee
           (SIMRAC), Johannesburg, 2002.

Wiles, T.D. (2007) Evidence Based Model Calibration for Reliable Predictions
           (pp. 3-20). Australian Centre for Geomechanics, Deep Mining.

rtTo ensure zero harm in underground workings it is necessary to ensure that the underground personnel understand what their actions are on the behaviour of the strata.

To achieve this normal training on Mine Standard, Codes of Practice and Work Procedures is not adequate on its own. Persons need to understand why this standard was introduced in the first place.

After Danie Snyman (Manager, Rock Engineering Support Services for Exxaro) found that too often production personnel interpret ground conditions incorrectly and then implementing control measures that was not only ineffective but also gave a false sense of security to the section personnel he decided to build a rock engineer training centre.

Picture: Exxaro RESS personnel at the entrance to the RETC

The Exxaro rock engineering training centre (RETC) is designed to help production supervisors to understand what factors affect strata stability. It also serves as an eye opener for all personnel, literate and illiterate, using practical models, photographs and sketches to demonstrate why certain control measures are effective and others not.

rt2    rt3
The first room is designed to teaches underground personnel about stress effects and how to manage it   Koos Wilken explaining the concept of stress using a simple model

The training centre is designed to follow a storyline discussing the different modes of strata failure, specific risk associated with these failures and effective controls to combat losses. The thinking process that a person must go through when conducting a proper rock engineering risk assessment is also included in the storyline. The Training centre is also aligned with the Exxaro rock engineering risk assessment template.

Models are designed and constructed to simulate and translate the complex mathematical concepts as manifested in the rock mass under different loading conditions. These models also had to be realistic and be understood by all levels of literacy.

Snyman using a model to explain how the length of a cantilever affects stability of the strata

Months of planning and deliberations went into designing the models and many sleepless nights transpired but finally one-by-one the models took shape and very positive feedback is received from everyone who passes through the centres' doors.

A model that explain how competent beams in the overburden results in longwall face breaks

Currently the centre houses about 60 models in four rooms but Snyman hope to increase this to at least 100 in the next few years.

The latest addition to the RETC is a six meter wide curved screen on which 3D virtual reality clips are projected

The 3D curved screen is housed in the auditorium

Was all this effort worth it? – Snyman will let Arnot's FOG accident stats do the talking


Below are some photos of the RETC

RETC Auditorium
Jointed sidewalls
Support material specifications

Written by: Danie Snyman
Manager Rock Engineering Support Services Exxaro Coal

On 5 March 2015, the SANIRE Eastern Bushveld Branch, in conjunction with Samancor, held a successful Strata Control Practical examination at Lannex Broken Hill Mine. The day began with a total of 17 candidates and 10 examiners arriving at Samancor ECM Central Offices, where a visitors' induction was conducted and underground plans provided to the candidates. The examination then proceeded to Lannex Broken Hill Mine where the candidates were taken to several underground observation points, from where the MG2 and MG3 ore bodies could be identified. After the underground portion of the practical exam, the candidates and examiners were treated to a delicious snack lunch by Samancor at the ECM Central Offices. The practical exam continued with candidates being individually tested by groups of two examiners for the entire paper, and negative marking was applied owing to the large number of candidates. Overall, the candidates did well, with 7 of the 17 passing the examination and obtaining their SCO Certificate. In general, candidates did very well in the plan reading, average in underground observations, and poor in the geological section. A big 'thank you' on behalf of SANIRE Eastern Bushveld Branch must go to Jimmy Kidd and Samancor for hosting a very well organised practical examination.


SANIRE has embarked on a new initiative to capture a series of video lectures, presented by SANIRE members and fellows who have made major contributions to the rock engineering fraternity. Our intention is to create two or three video lectures per year, which will be available for SANIRE members to view on the SANIRE website. This follows the example set by the International Society for Rock Mechanics (ISRM).  Currently there are nine online lectures available on the ISRM website and the most recent was presented by our very own Professor Dick Stacey (Professor Emeritus, University of the Witwatersrand) on 2015/04/16. SANIRE members are encouraged to suggest speakers and topics for future video lectures.
The first lecture can be watched here...

SANIRE Symposium 2015

SANIRE Free State is hosting a Rock Engineering Symposium: Unpacking the Aspects

Interesting topics from the entire industry: Gold, Platinum, Diamonds & Coal, etc. will be presented

Closing date for registrations and payments: 10 August 2015


Wilma Muller - 057 904 6498 wilma.muller@harmony.co.za  Fax: 086 519 8231


Alida Kleinhans - 057 904 6066 alida.kleinhans@harmony.co.za  Fax: 086 519 9155

Click HERE to register

First Announcement & Call for Abstracts

The First Southern African Geotechnical Conference will be hosted by the Geotechnical Division of the South African Institution of Civil Engineering (SAICE) under the auspices of the International Society for Soil Mechanics and Geotechnical Engineering (ISSMGE). This subregional conference will provide a forum for exchanging, disseminating and discussing current geotechnical practice in Southern Africa as well as sharing information of recent projects and developments. The venue for the conference will be Sun City in South Africa.

Important Dates

30 June 2015 Abstract submission deadline

31 July 2015 Notification of acceptance for the Abstracts

4 January 2016 Deadline for submission of the Manuscripts

29 February 2016 Notification of acceptance of the Manuscripts

31 March 2016 Submission of final paper

5 & 6 May 2016 Conference

Contact information

Michelle Stegen - RCA (Pty) Ltd - Conference Organisers

Email: events@rca.co.za  Tel +27 11 483 1861/62 Fax 086 653 7108



23–24 April, 2015 - Conference

Elangeni Maharani Hotel, Durban

25 April 2015 - Half Day Technical Visit

Harbour Entrance Tunnel Site Visit and Harbour Boat Cruise


This conference is in response to the Civil and Mining industry being under immense pressure to deliver projects fast, efficiently and as safely as possible. Mechanised underground excavation and support installation is proving to be an invaluable and cost effective tool in the execution of a project. Technology exists for mechanised excavation where tunnels can be excavated from as small as 300mm to in excess of 18 metres in order to access ore bodies, build road or railway tunnels, facilitate the installation of utilities, construct storage caverns for gas and oil, etc.

It is recommended that delegates interested in the mining application of tunnel boring attend both days.

 Registration Form

 Sancot - programme

 SANCOT Sponsor Opportunities Conference 2015(1)

 SANCOT-Second Announcement

harald3Harald was born in 1932 in Hamburg Germany. He went to school there until he was sent to Southern Germany to avoid the bombing during World War 2. Toward the end of the war he returned to Hamburg to help support his family in the aftermath of the war. After school he joined the Post Office in Hamburg and worked there for a short time. In about 1953 Harald came to South Africa, to join the Government Mines Training School and worked at Daggafontein and in the Klerksdorp area. He hoped to study mining at the University of the Witwatersrand, but eventually returned to Germany and studied at the Clausthal University of Technology. While there he was reunited with his best friend's widow, Else, and on graduating, returned with her and her son Jens to South Africa, where they married.

Once here he began work at Rand Mines' Durban Roodepoort Deep Mine in 1963 or 4. During the next 6 years he seems to have been involved in Rock Mechanics. At his instigation, a deep level tunnel on that mine was developed with an asymmetrically arched roof to mitigate stress effects. During the same period Harald completed a PhD at Clausthal, with research on stress measurement using overcoring. The stress regime at depth on DRD was measured as part of this research.

In 1970 he completed his thesis and was awarded his doctorate. Shortly after he left DRD and worked as an independent for a German company in Mocambique and other areas. The endeavour came to an end due to financial problems and Harald joined JCI as its first Group Rock Mechanics Engineer. There were no rock mechanics departments on individual mines in those days.

In the next 5 years the Chamber of Mines Group Rock Engineers Subcommittee and the Rock Mechanics certificate were established. Initially the Group Rock Mechanics Engineers were the examiners for the exams. They also examined the candidates underground during the practical exam.

In 1979 and 80 Harald began building up JCI's Rock Mechanics Department, sending his selected team member to Dr Stan Patchet's Anglo American Rock Mechanics unit in Welkom for training. Several later prominent Mining and Rock Engineers went through this process.

In 1979 he also had a serious motor car accident on the way home from one of the mines and spent months in hospital. He injured his legs, walking with a stick for years afterwards.

The experience of his staff was that he was prepared to back them up against the sometimes ruthless politics of JCI's head office and management.

Harald enjoyed sailing and kept a Muira keel boat on the Vaal Dam, where he often spent the weekend with his family, sleeping on the boat. In the 80s he got his skipper's license for ocean sailing off Durban, but after a couple of experiences of ocean cruising he lost interest in long cruises due to the loneliness and tedium.

He prided himself on being a linguist often correcting the English language of reports and letters. He also participated in Alliance Francais for many years. He was also a stickler for the correct notation of the metric system.

Harald questioned everything and loved debate. He had a wide interest in history, language and culture and loved to discuss these over a glass of wine.

He and his family explored much of Southern Africa in his Jeep Gladiator or Wagoneer, visiting remote natural areas and game reserves. They also travelled widely to Europe, Asia and America.

Harald reluctantly retired from JCI in 1992, but continued to travel and enjoy life for many years.

In the past 5 years he suffered from Parkinson's, which became increasingly debilitating. He passed away on 29 January 2015.

He is remembered fondly by many of those who worked with him, as well his family and friends.

A memorial service was held on the 15 February, attended by a very large number of friends, family and colleagues.

Eulogy by John James

This conference is in response to the Civil and Mining industry being under immense pressure to deliver projects fast, efficiently and as safely as possible. Mechanised underground excavation and support installation is proving to be an invaluable and cost effective tool in the execution of a project. Technology exists for mechanised excavation where tunnels can be excavated from as small as 300mm to in excess of 18 metres in order to access ore bodies, build road or railway tunnels, facilitate the installation of utilities, construct storage caverns for gas and oil, etc. It is recommended that delegates interested in the mining application of tunnel boring attend both days.

23–24 April, 2015 - Conference

Elangeni Maharani Hotel, Durban

25 April 2015 - Half Day Technical Visit

Harbour Entrance Tunnel Site Visit and Harbour Boat Cruise

Click Here to read more

Dear Members
Please follow the link to the latest bi-annual newsletter. Stories and articles are always welcome. Please email Paul Couto at Paul.Couto@Harmony.co.za for enquiries.

Download the PDF version: pdf  SANIRE Newsletter_Volume 1_Issue 1_January_2015 (4.31 MB)

or download the .pub version to publish the newsletter youreslf: default  SANIRE Newsletter_Volume 1_Issue 1_January_2015 (22.46 MB)

mike robertsDr Michael Roberts

26 January 1950 - 5 February 2015

Mike’s funeral took place on 11 February at St Michael’s Anglican Church in Bryanston. Mike’s wife, Kim, asked if I would pay tribute to Mike’s contribution to rock engineering research, and I was honoured to do so on behalf of our community. William Joughin asked if I would send a transcript of my eulogy to SANIRE. Here it is.

Kim, Lindsay and Georgie, family and friends, I want to honour Mike’s contribution to the science and practice of rock engineering in South Africa. I first met Mike when I joined the Rock Engineering Programme at CSIR in 1993. Mike was initially my mentor, as he was for many other young (and not so young) scientists and engineers. Over the next 15 years he became my colleague and friend.

Mike completed his BSc Honours in Geology at Wits in 1974 and his MSc in structural geology and rock mechanics at the Royal School of Mines, Imperial College in 1977. He then joined Randfontein Estates Gold Mine. He became the Rock Engineering Manager in 1981 at the age of 31 after getting his Rock Engineering Certificate.

Mike joined the Chamber of Mines Research Organisation, aka COMRO in 1985 (which became the Mining Technology Division of the CSIR, aka Miningtek, in 1993) and began a career in research that lasted 23 years. Mike’s tenure at CSIR was during a period that was something of a golden age for rock engineering research in South Africa. During this time

  • Mike made major contributions to the research conducted under the auspices of the Mine Health and Safety Council’s SIMRAC programme and the DeepMine Collaborative Research Programme, particularly with respect to the support of the face area of the stope, the most dangerous area of the mine. Stope support was the subject of his PhD in mining engineering, which he completed through Wits in 1999. The methodology he developed became the industry standard.
  • He authored or co-authored more than 50 papers, chapters in three rock engineering textbooks, and many research reports.
  • He was an NRF rated researcher.
  • He was the Manager of the Rock Engineering Programme at CSIR for four years (1996-2000), with a staff of between 70 and 90 scientists, engineers and technicians. Thereafter he stepped back onto the research track as a Research Fellow. He left CSIR in 2008 to join the consultancy firm, TWP.

That’s the data, but let me tell you more about Mike the rock engineering researcher.

Engineering may be defined as “the art or science of making practical application of the knowledge of pure sciences (such as physics, chemistry and geology)”, for example, to construct machines or to mine ore. Rock is often used as a metaphor for something that is strong and enduring. We who work in deep mines (and South African gold mines are, by far, the world’s deepest) know that highly stressed rock can be unstable and dangerous. Rock engineering is the discipline that seeks to master rock: to design and construct shafts, tunnels and stopes so that the ore can be mined safely and profitably. And this is the discipline of which Mike was a master.

Predicting the behaviour of rock is as much an art as a science, and we rely on “rock engineering principles” and often appeal to “engineering judgement”. One of the cardinal rock engineering rock principles is to “mine away from danger”. Mike was a key member of the Rockburst Task Force, which conducted forensic investigations into rockburst accidents. During a four-year period (1995-1998) we investigated over 30 rockbursts that had claimed the lives of more than 100 mine workers. In order to gather fresh evidence, we would go underground as soon as possible after the rockburst. Often the rescue teams were still digging for survivors or recovering bodies, the rock mass would not yet have been stabilised, or the ventilation restored. Mike had an incredible instinct for the underground environment. He usually went underground without clinorule, tape measure, camera, or compass. Like Sherlock Holmes, he would spot clues that most of us would miss (evidence of damage to rock, props, packs and bolts), and reconstruct the sequence of events, and recognise the sins of omission and commission that had contributed to the event. This took courage, endurance, and common sense. Mike calculated the risks carefully with a cool head.

A second rock engineering principle is “don’t resist an irresistible force with an immovable object”. Rather yield, absorb the excess energy, and keep capacity in reserve for another day”. Mike did not only apply this principle when dealing with rock and stope support, but also to people. Mining is a tough industry, but Mike was always quietly-spoken, and sought to persuade and encourage, rather than to command or intimidate.

While I have focused on his work achievements, we were very aware that rock engineering was not his sole priority. There were the four Fs: Family, Fishing, St Francis and Fast cars. Mike worked hard and smart, but seldom late.

Mike, as a representative of your friends and colleagues at involved in rock engineering research, I salute you for:

  • Your contribution to the science and art of rock engineering in South Africa;
  • For developing methods and technologies that have helped to make mining safer and more profitable – there are probably hundreds, if not thousands, of mine workers who owe their lives to the technologies that you helped to develop;
  • For training and mentoring a generation of rock engineers; and
  • For being a true scholar, gentleman and friend.

Ray Durrheim

South African Research Chair in Exploration, Earthquake & Mining Seismology

Mineral Resources Competency, Natural Resources & the Environment Unit, CSIR


School of Geosciences, The University of the Witwatersrand, Johannesburg

The Contribution of Rock Engineering to the Future of Mining

“Rock Engineering to the Rescue”

sym1 copyThe 11th of September 2014 saw the SANIRE Coalfields Branch hosting the annual SANIRE symposium for the second time since the 1989 SANGORM Symposium.

One of the very first annual SANIRE symposiums was held in 1986 and there have been more than 20 symposiums since then.

The decision that the 2014 Symposium would be hosted by the Coalfields Branch was taken at the SANIRE Bosberaad Meeting held on the 19th and 20th of October 2013, and since that day it has been all systems go for the Coalfields committee. All in all various members on the committee met to discuss the arrangements and planning more than 8 times over the following 9 months in the lead up to the Symposium to discuss, amongst other Rock Engineering related aspects, the requisite planning and arrangements for the Symposium.

Due to the extremely large scope and significant amount of planning and work that goes into the hosting of such an event, the Coalfields Branch committee took an informed decision to reach out to a number of additional SANIRE members within the coal industry for help with a number of different aspects related to the Symposium.

An individual who went out of her way to assist and advise wherever possible was the aptly named “Symposium Consultant” Lelanie Prinsloo. Lelanie was also responsible for the design of the dragline and roofbolter “goggo’s”, which would later adorn the brochures and posters.

Behind the scenes the Chairman’s wife Diane Petho was working tirelessly designing and compiling all of the brochures, announcements, posters, name tags, name lists and also selecting and wrapping the gifts, to ensure that everything on the day went along smoothly and in a professional manner.

The committee also took a decision to, as far as possible; ensure that the symposium had a more personal feel to it, for all of the delegates, from the Rock Engineering Practitioners to the Sponsor Representatives. A conscious effort was put in to ensure that each of the speakers, and event sponsors felt involved and was kept informed of the arrangements at all times.

One of the more difficult decisions that any organising committee has to make is the selection of the “ideal” venue. Due to the huge geographical area in which the Rock Engineering practitioners are located, as well as the fact that the exact number of delegates who typically attend the Annual Symposiums has been known to be particularly difficult to predict, a number of different venues had to be investigated.

One of the sponsor representatives, Danie Blom, took it upon himself to personally conduct a detailed investigation into all of the relevant different aspects of the potential venues in order to allow the committee members to make an informed decision regarding the selection of the venue.

Each venue was rated on aspects including cost, catering, parking, location, technical support etc. and based on the findings of the investigation; the committee took the informed decision that the symposium to be held on the 11th of September 2014 would be held at Glenburn Lodge.

Based on previous symposiums the initial number of delegates who were expected to attend the symposium was put at approximately 100, a number which proved in the end to be a gross underestimation.

As the date drew closer the names of delegates attending continued to pour in with the number of delegates attending having to be increased from 120 to 140 a mere two weeks before the event. Even so on the day the number of 140 proved again to be a slight underestimation with the final number of registered delegates on the day being 141.

After months of preparation, meetings and planning the day of the symposium finally dawned and 5:30am found the committee members arriving on site to finalise the venue preparation and ensure that everything was ready for the delegates when they started arriving at around 7:00am.

Thankfully, one of Mother Nature’s greatest variables, the weather, played along and ensured that the picturesque venue that Glenburn Lodge is could be enjoyed in all its splendour.

sym2 copy


sym3 copy

Generally the symposium was a huge success with the wide variety of topics ensuring that all of the approximately 141 delegates were kept interested throughout the day and that everyone was able to take home a number of valuable learnings relevant to their specific work environment.

The exceptionally high standard of presentation and supporting research was set from the onset with the key note address being given by Professor Nielen van der Merwe of Stable Strata Consulting who presented the most current research related to strength calculation formulas for coal pillars and the fact that so often in life, the more we know, the more what we thought we know, we need to change.

sym4 copy

The presenters who followed maintained the same high standard of research and presentation with topics ranging from, the monitoring of surface subsidence using satellite imaging techniques to, the effects of extremely high temperatures on the mineral properties of rocks and what geotechnical conditions could be anticipated when South Africa’s mining industry reaches ultra-deep level mining areas.

True to the common saying “last, but not least,” a highlight of the day was the presentation by Pieter Colyn which was in fact the very last presentation of the day, in which Pieter discussed his paper on the “Legal Liability of Rock Engineering Personnel,” a presentation which was unusually well attended for its position in the day’s proceeding, and quite understandably so.

As can be expected, there were a number of glitches on the day including some technical difficulties and simply the fact that the sheer quantity and value of the information which was to be communicated via the presentations on the day, resulted in what turned out to be a considerably long day, and a number of presentations running over time, literally “eating” into the break times and therefore impacting on the opportunity for delegates to network.

That said, all in all, it is safe to say that the 2014 national SANIRE Symposium, hosted by the Coalfields Branch, was a huge success, and that each and every delegate who attended on the day would have left that evening knowing that it was a day full of learnings and opportunities and ultimately one which was very well spent.

A big thank you needs to be extended to all of my fellow Coalfields Committee members for making the event a success. Also a special word of thanks needs to be extended to the videographers on the day, Dewald Swanepoel and Carl Krog, as well as the photographers Danie and Frik Blom, the father and son duo, for all their hard work behind the scenes.

Also a final word of thanks needs to be extended to all of our 16 sponsors, and 16 speakers for affording us the opportunity to present the Symposium.

We look forward to seeing you all next year when we as SANIRE, take the success of the 2014 Symposium and use it as a spring board to propel the SANIRE members as well as the mining community as a whole to even greater heights.

noelInterview questions

Full Name

Noel Delphin Fernandes


Group Rock Engineering Manager

Company/ Organisations

Impala Platinum Mines

Date and Place of Birth

1961/12/24 Virginia OVS


Barberton High School

First Job

Onsetter School Holidays, Electrical Apprenticeship Sheba Gold Mine in Barberton, then started as a learner official mining at Buffelsfontein Gold Mine.

Personal Best Achievement/s

Establishing a great rock engineering department which has stayed together for so many years. When rock engineers were travelling around following all the best paid jobs the Impala team stayed together. We fight a lot but all for the right reasons.

Philosophy of Life

If you don’t like it don’t do it. Life is too short to do something you don’t like to do.

Favourite Food/Drink

Typically porra, perri perri prawns and Coke

Favourite Sport

To watch Rugby and Athletics and did karate for many years. Now I get “milt steek” watching sport on TV.

Philosophy of Life: If you don’t like it don’t do it.
Life is too short to do something you don’t like to do.


1. How did your career in the mining industry begin and where are you now?

Started as a learner official mining 1983 and joined rock engineering in 1985 as an observer.

2. Why did you choose Rock Engineering?

Did not have the “balls” to do mining and asked for a transfer to rock engineering.

3. Please tell us a bit more about your career journey?

Not a nice story to tell but let me give it a shot. I was asked to leave the apprenticeship training facility at Anglovaal because of an argument with my trainer Mr Murning. Fortunately there was a vacancy for a mining learner official at Buffeltsfontein Gold Mine Gencor. Did not enjoy production and got into trouble for always arguing with my line management, was then transferred to the rock engineering department and have never looked back. Left Buffelsfontein Gold Mine in 1989 to join Vaal Reefs as an SCO, then joined Bafokeng South Platinum Mine (Impala Platinum) as a Rock Engineer stayed with them until 1996, joined Rustenburg Platinum from June 1996 to December 1997 and then returned to Impala Platinum end of 1997. Was appointed as the Rock Engineering Manager for Impala in March 1999 and was appointed Group Rock Engineering Manager for Implats in 2008.

4. In your opinion, what are some of the challenges that the fraternity is currently facing?

Firstly a lot of people have passed their rock engineering certificate lately and been pushed into rock engineering positions without the necessary experience, but this is a South African problem and we see it happening in the mining fraternity as well. Secondly the youngsters are getting involved with the setting of the examinations and practical exams. I believe here we lose a lot of the practical, hands-on issues that don’t get mentored to the newer generation. We need to blame the older generations as we don’t want to get involved enough and it will be nice to see them getting more involved again. Thirdly because the rock engineering fraternity is used by management and to a small degree the DMR to act as “policemen” to measure compliance, it is now becoming the responsibility of the rock engineering department to insure compliance. Compliance needs to stay the responsibility of line management.

5. What are some areas that you believe will become of increasing importance in the near future of the rock engineering discipline?

Historically Rock Engineering departments were small, but are getting larger and one will need to learn the skill to work with people.

“Surround yourself with people with different skills and people you can trust.”


6. What advice would you offer people aspiring to be in your position?

Be honest with yourself and with management, never shy away from telling the truth. It will at times cause constellation, remember rock engineers will never win a popularity contest with line management.

7. Who is your role model/ mentor?

I have been very fortunate to have worked with great leaders in the rock engineering. The first to come to mind is Roger More-O-Farrell, he was phenomenal with the rock engineering principles and he has the ability to surround himself with strong rock engineers who understood mining as well as rock engineering. In mining I worked for Senior Managers who were outstanding in their jobs such as John Smithies and Pieter Anderson but I must mention Mr Paul Visser who helped develop my management skills on how to get the job done and to trust the people working with me. Lastly Tinus Gericke has brought back the passion for the “job”.

8. What is the best advice you have ever been given?

The best advice I have ever been given was “Surround yourself with people with different skills and people you can trust.” I have been blessed to be surrounded with great hard working people of whom many have better skills than I have.

9. Who has influenced my life the most?

It might sound cliché my wife Anrea has really turned my life around, taught me to be more patient and caring. My team will testament to that, they say I have changed a lot and for the better. My daughters, they keep my feet on the ground, ready to tell me if I have messed things up.
